Vane motors

M Series

Brand: Danfoss

High-speed, high-pressure M Series vane motors are field-proven to provide years of successful operation in elevator scraper drives, hydrostatic drives and many more auxiliary applications.

  • Displacement from 21 to 317 cc
  • Pressure up to 175 bar
  • Rate speed up to 4000 rpm
  • Dual-pressure plate increases operational efficiency
  • Diametrically opposed inlet and outlet chambers reduce wear
  • Modular design permits greater serviceability
  • Low inertia of rotating parts results in smooth operation
  • Flange or foot mounting options allow for application flexibility
  • Inlet/outlet ports that can be pressurized simultaneously while maintaining smooth operation
Download datasheet
